Motor Operated Valve/ Electric Valve/ Check Valve
General
The HL-G2 motorized valve is a series of two-way motorized valves with screw connections. The valve and actuator can be separated into two units.When a thermostat sends the control signal to the motorized valve, the valve is opened to allow flow. When the signal disappears the valve will be completely closed by its spring.
Specifications
● Power Supply:AC220V±10% ,50/60Hz
● Self Power:<6.5W
● Nominal Presure:1.6MPa
● Action Time:
Opening Time:≤18s
Off time:≤7s
● Ambient Conditions: A
mbient air temperature:5~40℃
Median temperature:5~90℃
Beijing HaiLin Control Technology Inc.
