Motor Operated Valve/ Electric Valve/ Check Valve
General
The HL-G3 motorized valve is a series of three-way motorized valves with a threaded screw connection. The valve and actuator can be separated in two units.
When a thermostat sends the control signal to the motorized valve, the valve is opened to allow the water to flow. When the signal disappears the valve will be completely closed by its spring.
Specifications
● Power Supply: AC220V±10% ,50/60Hz
● Self Power: <6.5W
● Nominal Pressure: 1.6MPa
● Action time:
Opening time≤18s
Off time: ≤7s
● Ambient Conditions:
Ambient air temperature: 5~40℃
Media Temperature: 5~90℃
Beijing HaiLin Control Technology Inc.
